The novotegra green roof can now also be planned in Solar-Planit using landscape oriented modules. All orientations—south,
east/west, and
north/south—are supported. You can now flexibly arrange PV modules in landscape orientation on green roofs, benefit from adjustable row
spacing, and
receive, as usual, automatic structural analysis and ballast calculations, as well as dimensioned detail drawings in the PDF export.
Green Roof Substrate:
You can now define the substrate of a green roof in the roofing settings. Activate “Define substrate” and either select a substrate
from the catalog or enter your own substrate with name and dry weight (kg/m³).
With a defined substrate, the ballast calculation additionally outputs the required substrate height (cm) per module, so you can see
directly how much substrate is needed on the roof.
Version: 17.1.8 | Date: 08.09.2026
Added
Flat Roof II East-West:
novotegra FRII East-West now also supports disabling a single module within an East-West module pair.
This new feature enables the use of the East-West wind deflector to remove only one of the two modules, allowing the maximum possible system capacity to be installed on the roof.
The layout, including ballast calculation and bill of materials, is automatically adjusted, resulting in a clean project report without any manual rework.
Missing product images in the complete documentation.
Webshop prices for electrical items are now displayed correctly.
Decimal places in quotations were not being saved correctly.
Fixed an error message occurring in simulations with batteries.
Locked strings can no longer be deleted.
Version: 17.1.5 | Date: 12.08.2026
Improvements
Plannings can now be archived using the detail view in both the tile view and the project management view.
Version: 17.1.3 | Date: 04.08.2026
Changed
Old planning PDFs are not directly accessible anymore. PDFs older than one year will only be available via an email to your sales contact.
Version: 17.1.0 | Date: 30.07.2026
Improvements
Flat Roof II East-West now supports individual modules that can be deactivated. The new novotegra mounting solution allows individual modules to be replaced with a wind deflector, meaning that fewer modules often need to be omitted in the case of roof windows or other small obstacles. The design, including ballasting and the bill of materials, is adjusted automatically.
Version: 17.0.0 | Date: 18.06.2026
Added
Home & Project Management:
Your home page has a fresh new look. You can now return to your most recently opened planning and manage the status of your projects right from the home page.
Choose to work in Project Management, the tile view, or continue using the list view as before.
Version: 16.0.0 | Date: 16.06.2026
Improvements
Green roof:
The load-bearing capacities of the green roof props have been updated based on new tensile and compression tests — in many cases, higher loads are now possible.
In the PDF version, you can now also select module field details for green roof systems — including a detailed view of the mat layout for each module field.
Added
Green roof South:
Green roof South mounting system is now available for planning.
Select it under building type Flat roof → Type of roof covering → Green roof.
Row spacing can be set between 2.40 m and 2.60 m.
Version: 14.4.11 | Date: 11.05.2026
Improvements
String plans can now be fully edited: strings can be extended or shortened, individual modules can be removed, and module points can be moved to other modules.
Supplementary items are now included in the CSV export.
Help videos are now directly linked in the changelog to provide quick access to additional guidance.
Module load: Solar-Planit now displays the load acting on the PV module directly in the planning view and in the PDF report. This helps planners compare the calculated loads more easily with the manufacturer�s permitted load values.
Fixed
Position securing: Set for connecting the module fields to anchors fixed
Version: 13.11.2 | Date: 20.11.2025
Added
New logo added
Fixed
Rail cut plan: Rails are now extended by 3 cm at the end to make room for end caps.
Translations: Texts revised in the indicative price offer
Bulgaria: Wind and snow load calculations corrected
Version: 13.11.0 | Date: 06.10.2025
Added
New:
Position securing: Set for connecting the module fields to anchors with vertical threaded rod added
Fall protection: Contact request for Innotech added
Version: 13.10.0 | Date: 06.10.2025
Added
New Obstacle Detection feature
Available in plannings with background image
The Obstacle Detection is located in the right sidebar, next to the roof planner
Translation error in the indicative price offer fixed.
Prices of optimizers are loaded in the indicative price offer.
Version: 13.8.7 | Date 25.09.2025
Fixed
Snow load values for Norway corrected (Dlubal)
Version: 13.8.6 | Date 18.09.2025
Added
Export of the project in CAD formats DWG and DXF is possible
Version: 13.8.0 | Date: 26.06.2025
Added
Planning of fastening anchors from third-party manufacturers on pitched roofs with foil covering.
Version: 13.7.4 | Date: 5.05.2025
Detailed documentation for flat roof module fields
Added
For each module field on a flat roof, a separate page with detailed module field information such as ballast, dimensions, number of modules can now be output in the documentation.
Load profiles for E-Mobility
Load profiles for e-mobility can now also be selected in the yield simulation.
Version: 13.7.2 | Date: 15.04.2025
Added
Change history for Solar-Planit is now displayed.
A last page with legal notice and disclaimer has been added to the offer.
Changed
Article names are now also translated in the offer, if available.
The dimensioning factor is now easier to use in the inverter design.
Fixed
Incorrect translations have been corrected.
Prices in the offer are now also displayed when the items are hidden.
The download of incorrect electrical data sheets has been fixed.
The object address is now displayed correctly again for loaded projects.
Plannings on green roof now honor the minimal rail length.
